EFD

EFD.

Our standard FIFO injection unit

ERGONOMIC AND SUITABLE FOR MODULAR EXPANSION

  • Injection volumes ........................... 1,000 to 8,500 cm3
  • Injection pressure .......................................... 2,200 bar

ADVANTAGES

  • Low strip feeding height and machine height
  • High injection pressure of 2,200 bar
  • Smaller opening in the machine and heating plates
  • Cold runner-capable
  • Suitable for retrofitting with Rapid Cure Function for reduced cure times

HOW DOES IT WORK?

With first in - first out technology the initially plasticised material is the first injected into the mould. The constant screw length in this system guarantees even and consistent use of energy throughout the entire plasticising process. Due to the modular design it is possible to retrofit the EFD-injection unit, in order to obtain a FIFO-injection unit with Rapid Cure Function. This expansion stage, from EFD to EFE, offers considerable cure time reductions.
